As an important part of the refrigeration system, the installation process of the Air Dryer Desiccant must strictly follow a series of requirements to ensure that the equipment can operate stably and efficiently.
During the installation process, attention must be paid to details, from site selection, layout to specific installation steps, all need to be carefully planned and executed. Only in this way can we ensure that the Air Dryer For Air Compressor can play its due performance in subsequent use and provide reliable protection for the refrigeration system.
1. The Refrigerated Air Dryer should be placed in a room with an ambient temperature of 2-38℃, ensuring good ventilation and clean air around, especially avoiding the presence of corrosive components in the air, such as ammonia. If the indoor ventilation is not good, exhaust equipment needs to be added in the machine room.
2. To prevent the vibration generated by the air compressor from affecting the cold dryer, the distance between the two should be at least 4-5 meters.
3. For air-cooled cold dryers, the distance between the air inlet and the wall should be controlled at more than 1.5 meters, and the air inlets of the two dryers should not be opposite. There should be enough space around the cold dryer for daily repair and maintenance.
4. If the cooling water used by the water-cooled dryer is of poor quality, a filter should be installed at the cooling water inlet. At the same time, the temperature of the cooling water should be maintained between 10 and 32°C, and the water pressure should be maintained within the range of 0.15 to 0.35 bar.
5. The vibration generated by the dryer during operation is very small, and unless the foundation is soft, it is usually not necessary to make a cement foundation. When selecting the foundation, it should be ensured to be flat and stable to avoid the vibration of the air compressor transmitted from the air pipeline. If the vibration is too strong, you can consider connecting a high-pressure hose to eliminate the vibration.
6. The outlet of the automatic drain should be directly connected to the drain to prevent the drainage from polluting the production environment. At the same time, the height of the drain should not be higher than the drain to ensure smooth drainage.
7. When connecting the Refrigerated Air Dryer to the air source system, it is recommended to add a bypass pipe and a bypass ball valve between the air inlet and outlet for easy commissioning and maintenance.
